New Imaging “Blinks” So You Don’t Miss Proteins Causing Alzheimers & Other Age-Related Diseases

    By Kathleen Berger in collaboration with Washington University in St. Louis

    Tiny protein structures called amyloids are key to understanding certain devastating age-related diseases. Amyloids form plaques in the brain, and are the main culprits in the progression of Alzheimer’s and Huntington’s diseases.

    “In patients you see these huge plaques, but that’s the endpoint of the disease. It’s not the beginning,” said Matthew Lew, PhD, assistant professor in the Preston M. Green Department of Electrical & Systems Engineering at the School of Engineering & Applied Science.

    Lew explained how amyloids are so tiny that they can’t be visualized early in the disease progression using conventional microscopic techniques. He hopes a new imaging technique he helped develop will help doctors see amyloids in early stages of age-related diseases.

    “Maybe we can design therapeutics that can attack the disease at a more basic level before too many cells are killed, before you see the amyloid plaques in a CT scan,” said Lew.

    Lew and a team of engineers at Washington University in St. Louis developed a new technique that uses temporary fluorescence, causing the amyloids to flash, or “blink.”  This allows them to see the problematic proteins in real-time.

    Currently, scientists seeking to visualize amyloids use large amounts of a fluorescent material to coat the proteins in a test tube. When using a fluorescence microscope, the amyloids glow. However, it isn’t known how dyes that are permanently attached might alter the basic structure and behavior of the amyloid. It’s also difficult to discern the nanoscale structures at play using this bulk experimental technique.

    Lew helped develop the new technique that makes them blink. It’s called transient amyloid binding (TAB) imaging.

    TAB uses a standard dye called thioflavin T, but instead of coating the amyloids, it temporarily sticks to them one at a time. The effect isn’t permanent, and the amyloids emits light until the dye detaches, yielding a distinctive blinking effect. The researchers were able to use a fluorescence microscope to observe and record the blinks. They then localized the position of each blinking thioflavin and reconstructed a super-resolved picture of the exact amyloid structure.

    “What we saw were flashes of light over time,” Lew said. “On our computer screens, you’d see these individual spots blinking in sequence. We were then able to overlay all these dots together, giving us a complete look at the structure. If you didn’t separate them out, you’d see a blur.”

    The team tested the TAB technique on a variety of amyloid structures and were able to reconstruct images for all of them, over an extended period of time and at various stages of aggregation. Their results were recently published in the journal ChemBioChem.

    “There’s an intimate connection between seeing the proteins’ structure and learning how these proteins interact with neurons,” Lew said. “Ultimately, we need the imaging to understand all of the different shapes and structures that these proteins are building over time, and how that relates to the death of cells later on.”
